Sleeps 4
-
3 Slides
-
Rear Living AreaKitchen Island
-
36ft Long
-
12,900 lbs
-
Modern Farmhouse
32RLTS Floorplan
Specifications
Sleeps | 4 | Slides | 3 |
Length | 36 ft 6 in | Ext Width | 8 ft 6 in |
Ext Height | 13 ft 4 in | Int Height | 8 ft 6 in |
Interior Color | Modern Farmhouse | Exterior Color | White |
Hitch Weight | 2495 lbs | GVWR | 15500 lbs |
Dry Weight | 12900 lbs | Cargo Capacity | 2600 lbs |
Fresh Water Capacity | 75 gals | Grey Water Capacity | 87 gals |
Black Water Capacity | 50 gals | Tire Size | ST255/85R16E |
Furnace BTU | 40000 btu | Available Beds | King |
Refrigerator Type | Residential | Cooktop Burners | 3 |
Number of Awnings | 2 | LP Tank Capacity | 30 lbs |
Water Heater Capacity | 12 gal | Water Heater Type | Gas/Electric DSI |
AC BTU | 30000 btu | TV Info | LR 50" Smart LED HDTV, BR 32" TV, Ext. 32" TV |
Awning Info | 10' and 16' Electric with LED Lights | Axle Count | 2 |
Washer/Dryer Available | Yes | Number of LP Tanks | 2 |
Shower Type | Shower w/Seat | Electrical Service | 50 amp |
VIN | 1UJCF0BT1P1RV0066 |
Description
Jayco Pinnacle fifth wheel 32RLTS highlights:
- Walk-In Shower with a Seat
- Kitchen Island with Extension
- Tri-Fold Sofa
- Shoe Garage
- Exterior 32" TV
- Cedar-Lined Walk-In Closet
Trips to the lake are made comfortable in this triple slide out fifth wheel. Once you arrive at the campground, set up the two power awnings with LED lights, and there is an exterior TV for the big game. Head inside to relax on the theater seat directly across from the TV and fireplace, or play a game at the free-standing table. The chef of your group will love this Pinnacle kitchen with its residential refrigerator, kitchen island, a pantry, plus additional storage for canned goods or paper products. The full bath will allow you to stay clean throughout your trip, and you'll find a residential style backsplash in the bath, plus a shower with a seat for added comfort. Nothing says luxury like your own king bed slide out in the front bedroom, a walk-in closet for wrinkle-free clothes, and a flip-up dresser featuring a 32" TV!
Each Pinnacle fifth wheel features Stronghold VBL lamination for the lightest, yet strongest construction in the RV industry. Add that to the Magnum Truss XL6 roof system and Climate Shield zero-degree tested weather protection and you'll be enjoying your fifth wheel for years to come. Some of the exterior conveniences you will appreciate are the Keyed-Alike lock system, the fully enclosed, universal docking center, and the 6-point hydraulic auto-leveling system for quick and easy set up. The 5 Star Handling Package will make towing a fifth wheel a walk in the park, and the two Whisper Quiet A/C units will keep you comfortable during the hot summer months. Inside, you'll enjoy the farmhouse stainless steel sink, the handcrafted hardwood glazed cabinetry, the vinyl flooring throughout, plus many more comforts. There is even a central vacuum system, a wireless remote control system, USB ports throughout, plus many more conveniences to make each trip enjoyable.
Features
Standard Features (2023)
Standard Exterior Equipment
- Stronghold VBM™ aluminum framed and vacuum bond laminated gel-coated fiberglass exterior walls (including rear wall and slide room end walls)
- 12 in. structural steel I-beam with 10 in. steel drop frame.
- Magnum Truss™ XL6™ Roof System (strongest tested roof in the industry) with one piece, seamless roof and a 20 year warranty material
- Climate Shield™ zero-degree tested weather protection
- Fully enclosed and heated underbelly (ducted)
- 40,000 BTU output furnace
- Double layer fiberglass batt insulation (roof, floor, cap, and behind cap)
- PEX plumbing
- JaySMART™ (Safety Markers And Reverse Travel) LED lighting (patent-pending)
- Painted fiberglass front cap with built-in specialty LED lighting
- Frameless, dark tinted, safety glass windows
- Custom automotive-grade vinyl exterior graphics package
- 102" widebody construction
- Skirt metal enclosed drop frame
- LED exterior lighting package
- Dual 30 lb. propane bottles with auto regulator
- Doorside compartment framed and vented for third propane bottle
- Pass-through storage with Slam-latch™ baggage doors
- Digital TV antenna with Wi-Fi extender
- Exterior marine-grade speakers
- Fully enclosed, universal docking center
- Selectable water connections
- Quick-connect outside shower
- Black tank flush
- Winterization and sanitation
- Whole coach cable hookups
- Water heater bypass
- Battery disconnect
- Under-mounted spare tire
- JayPort outside griddle prep (standard on all floorplans without standard outside kitchen)
- Built in sewer hose carrier
- 3,000 lb. tow hitch with 4-way pin
- Inverter pre-wire to select outlets
- 12V heat blankets on all holding tanks plus 12V heat tape on fresh water line
Standard Interior Equipment
- Solid hardwood slide fascia
- Handcrafted and glazed doors, drawers and trim
- 5/8 in. tongue and groove joined plywood floor decking
- Vinyl flooring (Made in USA) throughout including slide rooms
- Ceiling fan (select models)
- LED interior lighting throughout
- LED accent lighting above slideouts
- Tri-fold hide-a-bed sofa with residential sleep surface (select models)
- Dual USB charging ports throughout
- 12V charging station
- JayVoice voice command system - controls lighting, A/C and furnace
- "Shoe garage" in hallway step (select models)
- "Flip-up" table top storage next to tri-fold sofa (select models)
- Soft close, heavy-duty, 75 lb. full extension, steel ball-bearing drawer guides
- Toe kick night lights in bedroom, bathroom and kitchen
- Pull-out spice rack above microwave (select models)
- Farmhouse stainless steel kitchen sink
- Residential-grade, pull-out kitchen faucet
- Extra 120V power outlets in kitchen and slide rooms
- Flip-up countertop extension with 24 in. x 24 in. butcher block bar top (select models)
- Pull-out utility drawer under kitchen sink
- Residential quilted bedspread and pillows
- Cedar-lined front wardrobe closet
- Gas-strutted under-bed storage
- P.A.P. prepped bedroom (includes 120V outlets and night stands)
- Carbon monoxide and LP detector
- Flip-up hidden storage in bedroom chest of drawers
- Built-in laundry hamper in wardrobe (select models)
- Cup holders in bedroom nightstands (N/A 36SSWS)
- Bathroom skylight
- LED backlit custom framed mirror
- Vessel bowl sink in main bath
- Porcelain toilet with foot flush
Customer Value Package (Mandatory)
- 15,000 BTU "Whisper Quiet" A/C with heat pump (main)
- 15,000 BTU "Whisper Quiet" A/C (bedroom)
- Electric patio awning with integrated LED lights
- Gas/electric DSI water heater
- Custom machined aluminum rims
- Keyed-Alike™ lock system (single key for all doors/locks)
- Rooftop and ground solar prep
- Backup, main entrance door and side observation security camera prep (includes a power switch in the bedroom to use the optional 7 in. monitor for security)
- Hidden hinges on cabinet doors
- XL grab handle
- Home entertainment system with subwoofer
- 50 in. 4K SMART LED HDTV with fully digital HDMI® output and two additional HDMI cables
- Wireless remote control system (includes Bluetooth® wireless interior controls) with dimmer switches
- Residential king (72 in. x 80 in.) mattress with under-bed storage
- Refrigerator temperature sensors linked to JAYCOMMAND®
5-Star Handling Package
- 16" Goodyear® Endurance® tires
- MORryde® rubber pin box
- Dexter® axles with Nev-R-Adjust® brakes and E-Z Lube® hubs, & 4,000 lb. leaf springs
- MORryde® LRE-4000™ rubberized suspension
- Wet bolt fasteners and bronze bushings
Luxury Package (Mandatory)
- 6-point hydraulic auto-leveling system
- MORryde® StepAbove™ entrance steps (main entrance) with strut assist
- 2nd electric patio awning with integrated LED lights
- Powered 50-amp cord reel
- JAYCOMMAND® “Smart RV” system
- Cellular prep for antenna and JAYCOMMAND®
- High gloss gelcoated sidewalls
- Oversized multi-battery compartment (industry leading room for 4-6 batteries)
- 32” 4K outside Smart LED TV
- Solid hardwood cabinet stiles
- Central vacuum system
- Day/night roller shades in living room
- Frameless dark tinted safety-glass windows
- Free-standing (no pedestal) table with leaf, 2 free-standing (with under seat
- storage) and (2) folding chairs
- LED fireplace with electric space heater
- Fresh Drinking Water System™ (patent-pending) for fresh drinking water at the kitchen sink and water/ice dispensers in the residential refrigerator
- Residential refrigerator with 1800W pure sine wave inverter
- 30” residential microwave
- Residential 24 in. Insignia™ stove (3.73 cu. ft. with 12K BTU high output burner)
- Residential solid-surface kitchen countertop with solid-surface sink covers
- 32 in. 4K Smart bedroom TV
- Residential walk-in shower with shampoo/soap holder/teak seat
- Washer/dryer prep
Options
- True interior design choice (Modern Farmhouse or Silver Mist)
- Truma on-demand hot water system
- Full body paint- Sand, Steel and Diamond
- Overlander II Solar Package (30 amp controller, (1) 800W inverter and (2) 200 watt solar panels)
- Wireless backup/side view/front entry door observation kit with 7in. monitor
- Sani-Con® Turbo waste management system
- Generator prep with 120 lb. max LP system includes (3) 40lb. LP bottles
- 5,500W Onan® Microquiet generator
- Frameless dual-pane tinted safety-glass windows
- Slideout awning (quantity varies by model)
- 7K Hydraulic disc brake package
- 8K Hydraulic disc brake package
- 3rd-15,000 BTU ducted A/C
- 18 cu. ft. Norcold® Polar Max gas/electric refrigerator
- Queen residential foam-top mattress
- Front wardrobe in place of front windshield and sofa lounge (36SSWS)
- Butler’s pantry (in place of half bath, 38FLGS)
- Outside griddle for JayPort system (32RLTS, 36FBTS, 36KPTS, 36SSWS)
- Overlander 4 Solar Package: (4) 200W solar panels, (2) 100-amp/hour lithium heated batteries, 60-amp controller, 3000W inverter, DC/DC power converter, soft start power save main 15K A/C, soft start power save for bedroom 15K A/C, battery monitor, energy management system, roof pre-wire for additional solar panels, generator prep capable and heavy gauge steel battery enclosure
- Overlander EXT Solar Package: 3,000W inverter/charger with internal 50-amp transfer switch, energy management system, (6) solar panels with 200W each, (6) 100-amp/hour lithium heated batteries, 12V DC A/C in bedroom, DC to DC battery charger, 100-amp MPPT controller management, generator prep capable
See us for a complete list of features and available options!
All standard features and specifications are subject to change.
All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.
Due to the current environment, our features and options are subject to change due to material availability.
